6000 Mm/S Fiber Laser Head

Large Image : 6000 Mm/S Fiber Laser Head

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	Tenfotai
Certification:	CE
Model Number:	TFT-FSP-10

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Please inquire individually
Packaging Details:	Carton
Delivery Time:	Within 5 days
Payment Terms:	T/T
Supply Ability:	1000 sets per month

Contact Now

Detailed Product Description

Mirror Length:	1064nm	Clear Aperture:	10mm
Marking Speed:	4000mm/s	Scanning Angle:	3.5 Mrad
Max Pulse Energy:	0.125mJ@40KHz	Pulse Repetitive Frequency:	1-150KHz
Highlight:	6000 Mm/S Fiber Laser Head , 3.5 mrad Fiber Laser Head , 6000 Mm/S galvo head co2 laser

Fiber Laser Galvo Scan Head

1. Product Description

TFT-FSP-10A is a 2-dimensional scanning system with 10mm incident light spot, widely used in laser processing, laser marking, laser welding, 3D printing and other fields;
The product integrates servo system, electric motor manufacturing and precision machining into itself, having high performance and high reliability;
Unique structure design ensures excellent heat transfer performance and shielding performance. Each component is manufactured according to the strict standard of low drift and high stability;
Adopting universal XY2-100 communication protocol to receive digital command, it’s applicable to different cards.

6000 Mm/S Fiber Laser Head 0

6000 Mm/S Fiber Laser Head 1

2. Technical Parameter

Dynamic Property:
Tracking Error	0.25ms
Long Time 8-hour Drift	＜ 30 mrad
Zero Point Drift	＜15 urad/k
Gain Drift	＜50 ppm/k
Photoelectric Property:
Clear Aperture	10 mm
Scanning Angle	±0.35 rad
Nonlinearity	3.5 mrad
Basic Property:
Mirror Wavelength	1064 nm
Marking Speed	4000 mm/s
Positioning Speed	3 m/s
Power Requirement	±15V DC, 3A each path
Working Temp	25℃±10
Interface protocol	XY2-100

3. Mechanical Drawing

6000 Mm/S Fiber Laser Head 2

4. Our Scan Head Production Workshop

6000 Mm/S Fiber Laser Head 3 6000 Mm/S Fiber Laser Head 4 6000 Mm/S Fiber Laser Head 5
